【intel程序猿笔记】英特尔® Edison编程环境间的数据分享

int notifier_pin         = 3;
int js_subscriber_pin         = 6;

FILE *fromarduino, *toarduino;
int i = 0;
int c;

// the setup routine runs once when you press reset:
void setup() {
  pinMode(notifier_pin, OUTPUT); //Notification pin
  pinMode(js_subscriber_pin, INPUT_PULLUP); //interrupt pin for reading message from JS
  attachInterrupt(js_subscriber_pin, subscriberEvent, RISING); //Subscribe to interrupt notifications from JavaScript
  Serial.begin(9600);
}

//Read message from js notification file
void subscriberEvent() {

   toarduino = fopen("/js_notification_out.txt","r");  //Opening message from JS
   if (toarduino)
   {
    while ((c = getc(toarduino)) != EOF)
    {
      if(c != 10)//new line
      {
           Serial.print((char)c);
      }
    }
    Serial.println("");
    Serial.println("----------------");
    fclose(toarduino);
   }
}

// the loop routine runs over and over again forever:
void loop() {
  if(i < 50)
  {
    i = i + 1;
  }
  else
  {
    i = 0;
  }

  publishData();
  notifyWorld();
  delay(1000);               // wait for a second
}

void publishData()
{
  fromarduino = fopen ("/arduino_notification_out.txt", "w+");
  fprintf(fromarduino, "[%d]", i);
  fclose(fromarduino);
}

//Nofity any body connected to this interrupt  (C++ program and NodeJS) program
void notifyWorld()
{
    digitalWrite(notifier_pin, HIGH);
    delay(200);
    digitalWrite(notifier_pin, LOW);
}
复制代码

var mraa = require("mraa");
var fs = require('fs');


/**********Read notification from arduino*************/
var subscriber_pin = new mraa.Gpio(1);
    subscriber_pin.dir(mraa.DIR_IN);
    subscriber_pin.isr(mraa.EDGE_RISING, subscriberEvent); //Subscribe to interrupt notifications from Arduino

function subscriberEvent() {
    var contents = fs.readFileSync('/arduino_notification_out.txt').toString();
    console.log("Message from Arduino:" + contents);
}

/********** Trigger message sending interrupt every 20 seconds *************/
var counter = 0;
var notifier_pin = new mraa.Gpio(5);
notifier_pin.dir(mraa.DIR_OUT);

setInterval(function(){
    counter++;
        fs.writeFileSync("/js_notification_out.txt", "NodeJS: [" + counter + "]\n");
        notifyWorld();
        counter = 0;
},20000);


function notifyWorld()
{
    notifier_pin.write(1);
    setTimeout(function(){
        notifier_pin.write(0);
    },200);
}
复制代码
